117MM 28V Inner Rotor Brushless motor 200RPM 1.2NM 25W
Loading...
| Model | M028BI1200-117-32 | Rated current(A) | 4.6 |
| No.of phase | 3 | Rated torque(N.m) | 5 |
| No.of poles | 30 | Rated output power(W) | 25 |
| No.of slots | 27 | Stall torque(N.m) | 7.7 |
| Winding type | Y | Insulation resistance | ＞50-MΩ（500VDC） |
| Rated voltage(VDC) | 28 | Insulation class | F(155℃) |
| F/L speed(rpm) | 245 | Operatiing temperature range(℃) | -25~+85 |
| Rated speed(rpm) | 200 | Operatiing relative humidity(RH) | 10-90 |
| Rated current(A) | 1.25 | Direction of roataion | CW&CCW |
| Rated torque(N.m) | 1.2 |
