86mm 3.6VDC Hybrid Stepper Motor 1.8° 11Nm
Specifications
|
Type |
Voltage /phase [V] |
Current /phase [A] |
Resistance /phase [Ώ] |
Inductance /phase [mH] |
Holding Torque [Ncm] |
Detent Torque [Ncm] |
# of Leads |
Weight [kg] |
Length [mm] |
|
M086HB6004-151S0 |
3.6 |
6.0 |
0.6 |
8 |
1100 |
24.5 |
4 |
5.0 |
151 |
