89mm 48V Roller Motor 2500rpm 44Nm 100W
| Model | M89-1050-0.3-400-48 | Rated power | 100W |
| Driving voltage | 48VDC | No-load speed | 2500±10%rpm |
| Phase | 3 | Back EMF | TBD±5%V/Krpm |
| Motor poles | 10 | Dielectric strength | 600VAC/2mA/1S |
| Rated torque | 44Nm | Insulation resistance | ≥50MΩ/500VDC |
| Rated current | 10.5A | Insulation class | F |
| Rated speed | 2500rpm | Weight | 16.5kg |
