Step Angle | 18° |
Rated Voltage | 5V |
resistance | 20±7%Ω/phase |
Inductance | 9±25% mH |
Holding torque | 60 gf.cm |
Insulation resistance | ≥100MΩ |
Dielectric strength | AC500V 1mA |
Pull out torque 200pps | 35gf.cm ref |
Detent torque | 14gf.cm ref |
Max pull out frequency | 450pps no load |
Max pull in frequency | 385pps no load |
